Features:
1. Based on unique box-building crimping technology.
2. Precision metallic alloy components with co-axial self centering, excellent and durable optical property.
3. Axially firm fitting of optical fibers, reducing any performance degradation due to loss in the matching gel.
4. Uninterrupted fitting and connecting technology, hence signals are free of impact from external force.
5. The naked fiber, tight buffer and cable, etc., can fully meet the environmental requirements from the terminals customer
6. Integrated protection of the casing to withstand harsh outdoor environment.
7. High success rate and easiness in installation with average splicing time of 150 sec;
8. Applicable for FTTx optical fiber splicing and for repairing any damaged lines to realize firm and reliable splicing of fibers.
SPECIFICATION
| Size | 45*4.2*4.7mm |
| Optical fiber diameter | 125μm ( 652 & 657 ) |
| Tight buffer diameter | 250μm & 900μm |
| Applicable mode | single & multimode |
| Operation time | about 10s (without fiber cut) |
| Insert loss | ≤ 0. 25 dB(1310nm & 1550nm) |
| Return loss | ≤ -45dB |
| Fastening strength of naked fiber | >5 N |
| Clamping force of fiber with tight buffer | >8 N |
| Using temperature | -40~+75°C |
| Reusability (10 times) | IL ≤ 0.2dB RL ≤ 5dB |
